SOLVED: Design and Implement a 2-4 "active-low" decoder using the gates on the chips. Your final circuit must include the ICs, their pin numbers, and the connections between the pins.6. Use the just constructed 4x1 multiplexer to design a three-input network that gives 1 if the majority of its inputs are 1 and outputs a zero otherwise.7. Use the 2-4 decoder to implement a 2-input function that acts like an equivalence gate: gives 1 on the output if both inputs are equal.Figure 4.1 shows some dig
